UnixWare ® 7.1.1
Data Center Edition

New Economics for the Data Center, New Power for Intel Processor-Based Servers

The UnixWare® 7 Release 7.1.1 Data Center Edition operating system is the newest addition to the UnixWare 7 product line. It is designed to meet the most stringent demands on performance, scalability and availability found in the corporate data center. With support for multiple levels of redundancy and support for servers with huge disk and memory capacity, the Data Center Edition brings data center power with significant cost savings over RISC-based UNIX server offerings. The Data Center Edition is licensed for 8 CPUs, 150 users and 32 gigabytes of memory, and can scale up from there.

Like all members of the UnixWare 7 product family, the Data Center Edition can be easily integrated with legacy systems and enables high-speed access to enterprise data through its rich networking subsystem. It includes a scalable, high-performance TCP/IP subsystem with industry-standard tools like DHCP (client and server), Sendmail 8.9.1, and Netscape Communicator,™ as well as many other features of Intel processor-based servers. Support for Windows® File and Print services is also built in. Coupled with a high-performance, highly scalable Java™ subsystem, UnixWare 7 enables businesses to gain excellent return on IT investment through a sound network computing architecture.

The UnixWare 7 Data Center Edition is designed to meet the performance and 24X7 availability demands of business-critical application environments. It delivers superior availability and on-line serviceability, by leveraging the latest innovations in industry-standard technologies such as Hot Plug PCI, Multi-path I/O and I2O. It also allows for redundant HBAs, network cards, and real-time management of data on redundant disks and file systems. It ensures that the information critical to your business is dependable, accessible and accurate.Taken together, these technologies have achieved above 10,000 hours of continuous operation (MTBSS.mean time between software stops) in SCO labs. UnixWare® 7 NonStop® Clusters takes this already high availability and scalability to a whole new level.

The UnixWare 7 Data Center Edition includes the built-in UnixWare 7 Webtop, which provides complete web-browser control of the system. Administrators and users can now take advantage of the power of the UNIX system using the familiar tools of the web.

Fully compliant with open industry standards, Year 2000 supported, and EURO-ready, the UnixWare 7 Data Center Edition provides a powerful platform for high-end-system builders. While other UNIX system vendors formulate plans for delivering UNIX servers to the enterprise on 64-bit Intel processors in the future, The SCO Group brings data center class technologies and performance on 32-bit Intel processors to the enterprise today, with a solid roadmap to 64-bit computing tomorrow.

UNIXWARE 7.1.1
Product Documentation


PDF version of this datasheet

Operating System

  • SVR5 symmetrical multiprocessing, multi-user, multi-threaded system
  • Licensed for 8 processors (expandable to 32 using Processor Upgrade license packs)
  • 150 Network User Licenses (optional add-on 10, 25, 100 and 500 user license packs)
  • 32 GB main memory (RAM) (optional upgrades to support 64 GB RAM)
  • Support for 16GB of General Purpose Memory
  • Year 2000 supported, EURO ready and UNIX 95 compliant. Includes compliance with XPG4, XPG4.2, SVID 4.2, POSIX 1003.1 and 1003.2 and FIPS-151-2 standards specifications. Binary compatibility for previous UnixWare 7 releases, SCO® UnixWare 2.x and SCO OpenServer™ from SCO applications

RAS Services

  • 1 TB files and file systems with capability for over 78,600 TB total capacity
  • High-performance, multithreaded, fault-resilient journaling file system with virtual file system support
  • Built-in disk striping, mirroring and spanning (RAID 1, 3, 5) with volume management via the included UnixWare 7 Online Data Manager
  • IP failover with NIC online restart/auto-start
  • Advanced hardware including Hot Swap devices, Multipath I/O, I2O and Hot Plug PCI

System Management and Serviceability

  • Fast installation with hardware auto-detection, from Bootable CD-ROM or over a network, and Upgrade Wizards
  • Auto-tuning kernel, integrated real-time performance monitor and system activity reporting
  • Software RAID and Online Disk Manager with visual administrator
  • Automated, unattended sever backup/restore with ARCserve®IT from Computer Associates v6.6
  • Enterprise manageable with SNMP MIB II support and graphical Intranet Manager
  • Event-logging subsystem for recording system and application events to and from SQL databases
  • Desktop Management Interface (DMI) API for DMI management station control administration
  • UnixWare 7 Webtop provides application and administration access

Internet and Network Support

  • Netscape FastTrack Server™ and Netscape Communicator™ 4, Java™ runtime environment and JDK™
  • Apache Web Server, Squid Proxy Server
  • Supports ISDN, 100mbps/1gbps Ethernet, FDDI, and Fast Ethernet devices
  • TCP/IP with high performance extensions, multicast support, IPv6 APIs, TPI NetBIOS
  • Multi-link, multi-domain PPP with DHCP, address allocation servers (AAS) and fast modem support. Supports up to 256 links and PPP over ISDN
  • Routing and gateway capabilities with RIPv1, RIPv2, OSPF, EGP, and BGP support
  • Integrated NetWare® UNIX Client, DHCP and bootp client and server support, and dynamic DNS
  • Multi-domain Sendmail, scalable message store, SMTP, MIME, POP3, IMAP4, LDAP directory server
  • Bundled RealNetworks® client and server for Internet streaming multi-media

File and Print Services

  • Windows (SMB) file and print services with SCO VisionFS™
  • Advanced Windows NT® Domain control and File and Print Services via optional AFPS add-on
  • NFS® (with NIS) and NUCFS (NetWare)
  • Optional NetWare Services (NetWare File, Print and Directory) add-on for NetWare clients

Security

  • C2-level security capability with predefined, selectable security profiles for maximum to low security
  • Powerful auditing and accounting tracks system access and security breaches
  • Identification and authentication, Discretionary Access Control and Access Control Lists
  • Trusted Control Facility for tightly controlled system owner and subsystem administrator authorizations
  • Static packet filtering and TCP Wrappers for network security

System Requirements

  • Supports PCI, I2O, EISA, ISA, MCA, PCMCIA systems with Intel® Pentium®, Pentium Pro, Pentium II, Xeon™, Pentium III, and 80486DX processors with supported network adapter (for networked installations).
  • Requires CD-ROM or network installation (requires another UnixWare 7 system).
  • Requires minimum of 500 MB free disk space. Recommended primary disk 1 GB.
  • 32 MB RAM minimum. 64 MB RAM recommended for CDE and other graphical applications.
  • SuperVGA adapter and monitor with at least 800x600 resolution required for graphical desktop.
  • Serial, bus or keyboard (PS/2-compatible) mouse recommended.
