UnixWare ® 7.1.1
Base Edition

Exceptionally Adaptable Platform for Specialized Server Solutions

The UnixWare® 7 Release 7.1.1 Base Edition operating system is the most advanced operating environment for network-centric, client/server or host-based business-critical systems using industry-standard Intel processors. Powered by the new SVR5 multitasking dynamic kernel, it is the ideal foundation for creating turnkey solutions where reliability and low cost are critical. Designed as a platform for building specialized systems, the Base Edition can be easily augmented with a powerful line of UnixWare 7 Optional Services that provide scalability extensions, reliability and availability extensions, file and print services, additional intranet services and messaging extensions.

The Base Edition provides all the key system services required for a standalone or networked platform including powerful multi-tasking support, unsurpassed scalability, fast TCP/IP networking, Internet mail services, Java and market-leading Netscape® Web-server technology. The system is loaded with ease-of-use and ease-of-management features, with particularly strong remote-management capabilities that work equally well over a dial-up or networked connection via the exciting new UnixWare 7 Webtop based on Tarantella web-enabling technology. System management can be performed via a character interface or graphical point-and-click SCOadmin managers. Administrators can completely automate batch processing or schedule routine administration tasks for off-peak, unattended completion by leveraging the Base Edition™s powerful scripting tools and system utilities.

You can easily tailor the Base Edition to maximize available hardware resources for dedicated-purpose solutions. It delivers the freedom of choice provided by industry standardcomponents and unparalleled reliability for deploying business-critical servers to deliver specialized functions such as computer telephony or self-service kiosks.

UNIXWARE 7.1.1
Product Documentation


PDF version of this datasheet

Operating System

  • SVR5 symmetrical multiprocessing, multi-user, multi-threaded system
  • Licensed for 1 processor (expandable to 32 using Processor Upgrade license packs)
  • 1 Network User License (optional add-on 10, 25, 100 and 500 user license packs)
  • 1 GB main memory (RAM) (optional upgrades to support 4 GB, 16 GB, 32 GB and 64 GB RAM)
  • Year 2000 supported, EURO ready and UNIX 95 compliant.
  • Includes compliance with XPG4, XPG4.2, SVID 4.2, POSIX 1003.1 and 1003.2 and FIPS-151-2 standards specifications. Binary compatibility for previous UnixWare 7 releases, SCO® UnixWare 2.x and SCO OpenServer™ from SCO applications

RAS Services

  • 1 TB files and file systems with capability for over 78,600 TB total capacity
  • High-performance, multithreaded, fault-resilient journaling file system with virtual filesystem support
  • Built-in disk spanning
  • IP failover with NIC online restart and auto-start
  • Supports hot swap devices, Multipath I/O, I2O and Hot Plug PCI

System Management and Serviceability

  • Fast installation with hardware auto-detection, from Bootable CD-ROM or over a network, and Upgrade Wizards
  • Auto-tuning kernel, integrated real-time performance monitor and system activity reporting
  • Software RAID and Online Volume Management via optional UnixWare 7 Online Data Manager add-on
  • Enterprise manageable with SNMP MIB II support and graphical Intranet Manager
  • Desktop Management Interface (DMI) API for DMI management station control administration
  • UnixWare 7 Webtop provides application and administration access

Internet and Network Support

  • Bundled Netscape FastTrack Server™ and Netscape Communicator™ 4
  • Apache Web Server, Squid Proxy Server
  • Supports ISDN, 100mbps/1gbps Ethernet, FDDI, and Fast Ethernet devices
  • Java™ runtime environment and JDK™
  • TCP/IP with high performance extensions, multicast support, IPv6 APIs, IPX/SPXII, TPI NetBIOS
  • Multi-link, multi-domain PPP with DHCP, address allocation servers (AAS) and fast modem support. Supports up to 256 links and PPP over ISDN
  • Routing and gateway capabilities with RIPv1, RIPv2, OSPF, EGP, and BGP support
  • Integrated NetWare® UNIX Client, DHCP and bootp client and server support, and dynamic DNS
  • Multi-domain Sendmail, scalable message store, SMTP, MIME, POP3, IMAP4, LDAP directory server
  • Bundled RealNetworks® client and server for Internet streaming multi-media

File and Print Services

  • Windows® (SMB) and Windows NT® file and print services with SCO VisionFS™
  • Advanced Windows NT Domain control and file and print services via optional AFPS add-on
  • NFS® (with NIS) and NUCFS (NetWare)
  • Optional NetWare Services (NetWare File, Print and Directory) add-on for NetWare clients

Security

  • C2-level security capability with predefined, selectable security profiles for maximum to low security
  • Powerful auditing and accounting tracks system access and security breaches
  • Identification and authentication, Discretionary Access Control and Access Control Lists
  • Trusted Control Facility for tightly controlled system owner and subsystem administrator authorizations
  • Static packet filtering and TCP Wrappers for network security

System Requirements

  • Supports PCI, I2O, EISA, ISA, MCA, PCMCIA systems with Intel® Pentium®, Pentium Pro, Pentium II, Xeo™, Pentium III, and 80486DX processors with supported network adapter (for networked installations).
  • Requires CD-ROM or network installation (requires another UnixWare 7 system).
  • Requires minimum of 500 MB free disk space. Recommended primary disk 1 GB.
  • 32 MB RAM minimum. 64 MB RAM recommended for CDE and other graphical applications.
  • SuperVGA adapter and monitor with at least 800x600 resolution required for graphical desktop.
  • Serial, bus or keyboard (PS/2-compatible) mouse recommended.

UnixWare 7 Editions Include
